Dear Customers, 2017 China National Days and Mid-Autumn Festival is coming, we will have holidays from Oct. 1st to 8th. Oct. 9th (Monday) back to work. Kindly contact our sales rep for any issues in this period. Sorry for the inconvenience of you. Best regards. --------------------------------------------------------------------------------- Owen Hua Nanjing Hecho Technology Co., Ltd Mobile: +86 133 8200 9944 Phone: +86 -25 5236 0905 Fax: +86 -25 5237 4095 E-mail: owen@gohecho.cn WebSite: www.gohecho.com Address: 6Floor, No. 381, Pugang Street, Nanjing 211102, China Manufacture: Fiber Optic Bundles, Fiber Optic Illuminators, Fiber Optic Sensors... ---------------------------------------------------------------------------------

The core is the central region where the refractive index of the transmitted light in the optical waveguide is higher than that of the adjacent region. For the step-type refractive index distribution fiber, the core is a cylinder containing a fiber core with a high refractive index. As the optical Fiber Optical Transmission layer called cortex, also known as cladding, for the step-like refractive index distribution fiber, the cortex is the lower refractive index of the ring outside the core, see the following figure. Optical fiber coating layer is coated with a layer of protective fiber material, referred to as fiber coating, also known as coating or buffer layer or fiber coating, optical fiber coating not only has to maintain fiber strength, to prevent fiber micro Bending loss and the ability to prevent fiber damp, but also reduce the mechanical damage of the fiber, and some fiber coating also has a specific physical variables sensitive to the characteristics can be used for sensing measurements, the typical coating materials, including acrylic resin, silicon Resin, ethylene-tetrafluoroethylene copolymer, polyurethane and polyimide, see the following figure. The cladding mode is a mold that is transferred and held in the fiber cortex. Usually, a cortical material that absorbs or attenuates the cladding mode is used to prevent the transition of the cladding module energy into a core, Thus reducing the dispersion, cladding mode, also known as cladding mode. Hecho specializing in manufacture Fiber Optic Cables, Fiber Optic Bundles, Fiber Optic Sensors, and Fiber Optic Illuminators for over 10 years. We supply a complete solution for Optical Fiber transmission. OEM service is welcome.

Optical fiber (referred to as fiber) has a lot of types. According to the materials used in the manufacture of optical fiber classification as Quartz Fibers, Multi-component Glass Fibers, and Plastic Optical Fibers. According to the light in the fiber transmission mode can be divided into: Single-mode fiber and Multi-mode fiber. Cross section Refractive index Light propagation Fiber types Multimode - step refractive index Single mode - step refractive index Multimode - gradient refractive index The optical fiber is classified on the one hand according to the refractive index distribution of the core profile, and on the other hand, according to the number of patterns transmitted. As described above, it is divided into single-mode optical fiber and multimode optical fiber. According to the profile refractive index distribution is divided into step optical fiber, gradient refractive index optical fiber and special profile refractive index distribution optical fiber. Step Refractive index The refractive index of the optical fiber over the entire cross section is constant. Gradient Refractive Index The optical fiber cross section is non-linear, rotationally symmetric, and the refractive index decreases from the center to the edge. Step Refractive index The refractive index of the multimode optical fiber is constant, so its distribution index g = α. Gradient Refractive Index The refractive index of the optical fiber decreases from the center to the edge. The light travels along the axis of the optical fiber, rather than straight. Nanjing Hecho Technology Co., Ltd. supply glass fiber, plastic optical fiber and quartz fiber products, including Fiber Optic Bundles, Fiber Optic Sensors, Fiber Optic Cold Light Source, please call us freely!

Fiber Optic Bundles is the core component of fiber optic lighting, the bundle is generally composed of optical fiber material, interface and protection tube composition. How to choose a suitable Light Guide? First, we determine the spectral requirements used. In general use, the spectrum is generally divided into three parts. UV to visible light (190nm-1200nm), visible light (380-780nm), visible to near infrared (400-1400nm) Far infrared part (400-2500nm). The four parts correspond to the optical fiber materials of different materials. (380-780nm) Optional plastic optical fiber or glass fiber, visible to near infrared part (400-1400nm), optional glass fiber, visible to far infrared part (400-2500nm) Optional infrared fiber. Second, according to the use the environment to determine the use of temperature range, glass fiber and quartz fiber can withstand higher temperatures, plastic fiber generally can only withstand 75 degrees or less. At the same time fiber in the production need to use adhesives, conventional fiber adhesive temperature within 180 degrees, if the use of temperature higher than 180 degrees, need to choose a higher temperature resistant high temperature fiber adhesives. At present the general high temperature fiber adhesives can work long-term 350 degrees. Third, confirm the shape of fiber, generally summarized the Fiber Optic Bundle has the following shapes, Single Light Guide, double-tube, multi-branched light guide, Ring Light Guide, linear light guide, multi-input multi-output type. After determining the shape, the dimensions of the parts at both ends of the optical fiber bundle are determined simultaneously. At the third step, the fiber bundles need the protective tube, such as stainless steel tube, stainless steel outer plastic coated tube, etc. Hecho supply OEM service for Fiber Optic Bundles, Fiber Optic Sensors and Cold Light Source, if any related items required, pls contact us freely.

In the fiber optic lighting, due to the optical fiber is only a light transmission carrier itself does not light, so inevitably need to choose the cold light source. The cold light source, is the light emitted by the light generated in the heat part of the infrared light effectively filtered out. We are common in the market with cold light source is mainly divided into Metal Halide lamp cold light source, Halogen Light Source and LED Cold Light Source. Metal halide lamp cold light source is characterized by luminous efficiency can reach 80-90 lumens / watt, color rendering index can reach more than 90. Spectral range is relatively wide, good quality metal halogenated lamp life can normal use around 5000 hours. Where the need for high-intensity lighting, metal halide lamp cold light source is a common choice, the disadvantage is its relatively high price, start requires a special trigger, because its brightness is gradually increased, start more slowly. Halogen lamp cold light source is characterized by luminous efficiency is generally 30-50 lumens / watt, color temperature is generally 2700-3200K, color rendering index is generally more than 80. The rated life of the lamp is 50-1000 hours. Generally in the fiber cold light source, the halogen bulb with ellipsoid reflector condenser. The use of power is generally 50-250W, because of its luminous efficiency in general, more than 100 watts of power use, the convergence of light after the focus point temperature will be high, so the halogen light source in the selection of the need to pay attention to its insulation and heat, If it is not done effectively, the high temperature generated by its focus will burn out the end face of the fiber. LED cold light source is the fastest growing product in recent years. White light LED light source color temperature 2700-6500K, color rendering index 70-92, the service life of up to 30,000 hours because of its high luminous efficiency, fast response and long life, the overall power of small energy saving, so more and more Occasions are gradually using LED cold light source. The white light of the LED cold light source defect is that its emission spectrum is not continuous spectrum. At the same time LED light source light-emitting chip luminous angle is relatively large, the coupling fiber requires secondary optical light distribution, secondary optical light distribution efficiency of its overall effective output is very important, so the power is not the higher the higher the illumination value , More important is to see the effective output of the luminous flux parameters. In summary, in the choice of fiber optic lighting supporting the Cold Light Source, if the spectrum has a higher demand, you can choose metal halide lamp cold light source and halogen light source, if the service life and control the response speed requirements Choose LED cold light source. With the continuous development of LED semiconductor technology, more powerful LED light-emitting chip is also constantly introduced, the effective luminous flux output will be higher and higher, coupled with the optimization of the secondary optical design, the overall over the metal halide lamp cold light source And the effective output of the cold light source of the halogen lamp is entirely possible. At the same time more than a few cold light source, need to pay attention to its cooling design, whether the effective isolation of the light part of the infrared light.

Plastic fiber optic according to the different materials of fiber core is generally divided into PS plastic fiber, PMMA plastic fiber and batch PC plastic fiber. At present, conventional large quantities are mainly used for PS plastic optical fiber and PMMA plastic optical fiber. PMMA plastic optical fiber is widely used in functional lighting and sensing. PMMA plastic fiber loss is 150-300 dB/km according to different fiber diameter. Spectral transmission range is 380nm-780nm. In the museum lighting or commercial display lighting, the designer most need is to damage the exhibits of UV and infrared light and heat effectively isolated, and plastic fiber because of its own characteristics just in line with this requirement. There's kinds of plastic optical fiber in the Fiber Optic Sensor, generally we need to consider the following factors: First, according to the detection distance selection, if the detection distance is far, as far as possible to choose the fiber core by the thicker fiber. If the detection target is small, the optional numerical aperture is smaller or additionally with the condenser lens. Second, according to the size of the space, whether the need for smaller turn to install. The larger the core diameter of the plastic fiber, the greater the corresponding minimum bending radius, and the more light it consumes when it is smaller. So we can choose as much as possible when the choice of fiber monofilament core finer. Currently available on the market the smallest bending radius of the plastic fiber up to R0.5 mm. Third, according to the use of ambient temperature, conventional plastic fiber temperature at 75 degrees, if the use of the occasion temperature exceeds this, the plastic fiber will be deformed and dramatically increase the loss. Currently available on the market at a higher temperature of 85 degrees level 105 degrees and 150 degrees level, it should be noted that with the plastic fiber temperature performance improvement, and will be accompanied by increased wear and tear. Nanjing Hecho Technology Co., Ltd. Supply high quality imported Mitsubishi plastic fiber, Toray plastic optical fiber, Asahi Kasei plastic optical fiber and Self-coated domestic plastic fiber, complete specifications, adequate inventory, short time delivery. And to provide plastic fiber optic cable using the selection of technical support.

Fiber optic lighting is transmission the light through optical fiber from light source to the designated area. Fiber Optic Lighting has the following characteristics: 1. Theoretically, the light can be transmitted to any place, to meet the practical application of the various requirements. 2. Through the filter to obtain a variety of colors of light to meet the different circumstances of the light color requirements. 3. Through the end of the fiber to make lighting from the abstract into a visualization. 4. Optical fiber lighting to achieve the photoelectric separation, improved safety performance, and broaden the application areas. 5. Plastic optical fiber lighting system soft color, no light pollution, soft color pure. 6. Some special occasions lighting, need infrared and ultraviolet light, such as cultural relics. The spectral range of the plastic optical fiber is located in the visible light section, and the light emitted from the fiber is cold light without infrared and ultraviolet light. 7. The use of fiber-side light-emitting system, the configuration of underwater-type terminal for underwater lighting system, and can be output by the audio system audio signal synchronization control light output and light color transformation. Its lighting effect and safety is better than ordinary low-pressure underwater lighting system, photoelectric separation, no leakage risk. Hecho Fiber Optics provide a complete optical fiber transmission solutions, with more than 10 years production experience, can meet customers' various requirements. Our featured products including Fiber Optic Bundles (Fiber Optic Light Guide), Fiber Optic Light Source (Fiber Optic Illuminators), Fiber Optic Sensors, etc. For more information, please visit Hecho Technology website: www.gohecho.com

At present, the microscope lighting method can be divided into two types of transmission and lighting. The illuminated light beam is emitted from the direction of the objective lens to the surface of the object to be observed, emitted or diffracted by the surface of the object, and then returned to the objective lens. Therefore, the ejection lighting is mainly used for observing metals and opaque objects such as ores, insects or circuit boards. For the fine observation of the circuit board PCB, in particular, need to observe the fine lines, requiring the microscope lens is close or close to the observation, the objective lens is basically attached to the circuit board, based on existing LED Light Source or Halogen light source lighting system can not achieve light focus, it is difficult to achieve litter lighting. Hecho provide a complete optical fiber transmission solutions, we have over 10 years experience in production, according to customer requirements for the production of optical fiber products, such as Fiber Optic Bundles (Light Guide), Fiber Optic Light Source, Fiber Optic Sensors, etc. For more information, please visit Hecho Technology website: www.gohecho.com

Optical Fiber Sensor is the optical signal from the light source through the optical fiber into the modulator, so that the parameters measured with the light entering the modulation area after the interaction, resulting in optical properties of light changes (such as light intensity, wavelength, frequency, phase, polarization, etc.), become the modulation of the signal source, and then through the optical fiber into the photodetector, after demodulation, access to the corresponding parameters of the target. Sensors are moving in a sensitive, precise, adaptable, compact and intelligent direction. In this process, fiber optic sensors much favored by the market. Optical fiber has many excellent properties, such as: anti-electromagnetic and atomic radiation interference performance, fine, soft, light weight mechanical properties; insulation, no induction of electrical performance; water, high temperature, corrosion resistance Chemical properties, etc., fiber can be in people can not reach the place (such as high temperature area), or people harmful areas (such as nuclear radiation area), receive and transmit a variety of information. HECHO provide a complete solutions for fiber optic transmission, we are famous a variety of Fiber Optic Sensors Manufacture, use the imported high transmission rate of glass fiber or plastic fiber for production, including M3 / M4 / M6 Sensor Fiber Optic Sensor Thread Connection, Cylindrical connection type sensor fiber, Heat Resistant Fiber Optic Sensors, regional detection sensor fiber, liquid level detection sensor fiber, etc., which can be Replace KEYENCE Optic Sensors, omron, sick and other brand fiber optic sensors. Hecho provide OEM & ODM services, all kinds of non-standard fiber on-demand customized. For more details, pls visit our website: www.gohecho.com

Optical fiber is a glass or plastic made of fiber, which can use the "light of the total reflection" principle as a light transmission tool. The propagation of light in any medium will be lost due to absorption and scattering, but some measures can be taken to reduce the loss of light over long distances. This includes: the use of ultra-pure quartz glass to reduce impurities in the optical fiber; try to improve the internal structure of the glass uniformity; the use of long wavelength of laser conduction, in order to improve the transmission of optical fiber effect. HECHO choose imported high transmission rate of Germany Schott glass fiber and Japan's Mitsubishi, Asahi Kasei, Toray plastic optical fiber materials, to produce various Fiber optic bundles, Optical fiber sensors and other fiber optic products, to provide complete Fiber optic transmission solutions to meet the industry's use of the environment and application. If you have any related project or questions, pls feel free to contact us.

On March 14, 2017 - 16, Nanjing HECHO Technology participated in the 2017 Shanghai PHOTONICS CHINA Exhibition. As the largest laser, optics and optoelectronic industry event in Asia, from the basic research to the industrial application, the Munich Shanghai Optical Fair leads the industry development trend, focusing on laser and optoelectronics, optical and optical manufacturing, laser production and processing technology, imaging, Quality control of the four sections of the full range of product content, is not to be missed the industry exhibition. This exhibition, HECHO technology display traditional advantages of optical fiber bundles, fiber optic sensors, fiber optic light source and machine vision light source, and grand launch of the new high-power LED light source S5000 and endoscope LED light source module, which won the majority of the old and new The customer's affirmation and praise, also made valuable comments and suggestions. Three days of the successful conclusion of the show, sincerely thank you to visit the new and old customers, HECHO technology will provide you with more professional fiber transmission solutions.

Hecho will attending PHOTONICS CHINA 2017 from March 14th to 16th. We will showcase the latest high power LED cold light source, Halogen light source, Fiber optic bundles, Fiber optic sensors, welcome to visit our booth at N2.2186.
